Model :
FR3
The FR3 bike is offered low – medium – high speed, long range and affordable price to the people who need it to go the position he want.
Our R&D engineer designed this mobility scooter with the most safety and convenient way as he is disable people that this scooter has its features to meet their actual demands. Only the mobility scooter is designed by the person who knows what their needs that is the best one.
Set up stylish LED headlight, brake light and direction lights to have safety installation when running in the night; the seat is comfortable and we have 3 patents –
1. Unique folding structure – easy folding and the bike after folding, it can be stored in the trunk of car.
2. Automatically correct balance brake adjustment (the function is similar to the differential devise)
3. Speedy with easy folding seat armrest (Traditional design breakthrough & prevent the weak legs to fall down from the footpad)
It is with 3 different speed settings on this scooter to meet various customer’s requirement.
| Description/Model | FR3 |
| Geared Motor | 36V / 350W Brushless wheel housing |
| Lithium Battery | 36V/11.6Ah |
| Endurance | 25~35km (80kgs loading on flat testing) |
| Charger | 100V ~ 240V / 2Ah |
| Charging time | 5-6H |
| Max. speed km/h | 25 |
| Adjustable speed on LCD | 3 gear (9km/h，18km/h，25km/h) |
| Reverse speed km/h | 3 |
| Brake system | Front disc + Rear double disc with automatic correction balance brake system (Patent) |
| N.W. (kgs) | 26 |
| Radius of gyration (cm) | 83 |
| Climbing angle | 10 degree slope length 25 meters |
| Tire dimension (Front/Rear) | 10" (10*2.125、10*2.5) |
| Seat height (Off the ground) | 54 cm |
|
Max. loading (kgs) km/h |
100 |
| Scooter dimension (cm) | Length 110*Width 56(Adjustable to 69cm)*Height89 |
| Folded dimension (cm) | Length105*Width56*Height53 |
- Safe & stable * practical and convenient mobile car
- Suitable for elderly and people with reduced mobility
- Easy to fold, easy to carry, and can be boarded on planes and trains.
- The safest, practical and best transportation tool
- Can travel by plane, high-speed rail, bus, etc.
- Can be placed in the rear storage of a normal car
